The APC Smart-UPS On-Line SRTG6KXLI is a high-density, double-conversion online UPS designed for mission-critical environments such as data centers, enterprise IT, and industrial applications. Manufactured by APC by Schneider Electric, this UPS delivers pure sine wave output, zero transfer time, and scalable runtime options, ensuring uninterrupted power even in the most demanding conditions.

Why Choose APC Smart-UPS SRTG6KXLI?

Power disruptions can cause data loss, hardware damage, and operational downtime. The SRTG6KXLI addresses these challenges with true online double-conversion technology, internal bypass, and intelligent battery management. It is ideal for servers, networking gear, and sensitive electronics that demand consistent, clean power.

Core Features

• 6kVA / 6kW Capacity: Supports large IT loads and networking devices.
• Double-Conversion Online: Provides the highest level of power conditioning.
• Rack/Tower Convertible: Flexible installation for evolving IT environments.
• LCD Display: Real-time monitoring of UPS status and alarms.
• Network Management Card: Enables remote monitoring and control.

Performance & Reliability

The SRTG6KXLI uses sealed lead-acid batteries with a life expectancy of 3–5 years. It offers internal automatic and manual bypass, ensuring continuous operation during maintenance. With an efficiency of up to 93.5%, it reduces energy costs while maintaining reliability.

Applications

• Data Centers & Server Rooms: Protect servers and storage systems.
• Network Infrastructure: Ensure uptime for switches, routers, and firewalls.
• Healthcare & Finance: Maintain continuity for critical applications.

Safety & Compliance

Certified under CE, UKCA, and IEC standards, the SRTG6KXLI meets global safety requirements. It includes audible alarms, LCD indicators, and surge protection for enhanced security.

Energy Efficiency & Sustainability

APC’s Green Premium™ label guarantees compliance with environmental standards and optimized energy performance.

Technical Specifications

• Model: SRTG6KXLI
• Capacity: 6kVA / 6kW
• Topology: Double-Conversion Online
• Input Voltage: 230V AC (Range: 160–285V)
• Output Voltage: 230V AC (Configurable 220/230/240V)
• Output Connections: 2 IEC C13 + 1 IEC C19 + Hardwire (1P+N+E)
• Rack Height: 4U
• Waveform: Pure Sine Wave
• Efficiency: 93.5% at Full Load
• Frequency: 50/60Hz Auto-Sensing
• Bypass: Internal Automatic & Manual
• Battery Type: Sealed Lead-Acid (VRLA)
• Battery Voltage: ±96V DC
• Recharge Time: 4 Hours
• Battery Life: 3–5 Years
• Extended Runtime: Supports up to 4 external battery packs (SRTG192XLBP4)
• Surge Energy Rating: 600 Joules
• Control Panel: Multifunction LCD Status Console
• Interface Ports: USB, RJ-45, SmartSlot
• Dimensions: 178mm (H) × 440mm (W) × 620mm (D)
• Weight: 51.9 kg
• Operating Temp: 0–40°C
• Humidity: 0–95% RH Non-Condensing
• Noise Level: 55 dBA
• Protection Class: IP20
