APC Smart-UPS RT SRTG10KXLI 10kVA/10kW, 230V, Double-Conversion Online, Tower/Rack, LCD Display, Hardwire Input, 2×IEC C13 + 1×IEC C19, Internal Bypass, 192V External Battery Pack

Brand: APC

USh20,500,000  USh22,000,000

  • Capacity: 10kVA / 10kW
  • Topology: Double-Conversion Online
  • Input Voltage: 230V AC
  • Battery Voltage: ±192V DC
  • Recharge Time: 4 Hours
(Available)
Quantity

The APC Smart-UPS RT SRTG10KXLI is a high-performance, double-conversion online UPS designed for mission-critical environments such as data centers, enterprise networks, and industrial applications. Built by APC by Schneider Electric, this UPS ensures continuous, clean, and reliable power for sensitive equipment, even during severe power disturbances.

Why Choose APC Smart-UPS RT 10kVA?

Power outages and voltage fluctuations can cause catastrophic failures, data loss, and downtime. The SRTG10KXLI addresses these challenges with advanced features like true online double-conversion, internal bypass, and scalable runtime using external battery packs. It’s ideal for environments where uptime is non-negotiable.

Core Features

  • 10kVA / 10kW Capacity: Handles heavy loads for servers, storage, and networking gear.
  • Double-Conversion Online Topology: Provides consistent, regulated power regardless of input fluctuations.
  • LCD Display: Real-time monitoring and easy configuration.
  • Extended Runtime: Compatible with 192V external battery packs for prolonged backup.
  • Hot-Swappable Batteries: Zero downtime during maintenance.

Performance & Reliability

The UPS delivers pure sine wave output with less than 2% harmonic distortion, ensuring compatibility with sensitive electronics. It includes automatic and manual bypass, emergency power off (EPO), and network management card for remote monitoring.

Applications

  • Data Centers: Protect critical servers and storage arrays.
  • Industrial Control Systems: Maintain operational continuity during power anomalies.
  • Healthcare Facilities: Ensure uninterrupted power for medical equipment.

Safety & Compliance

Certified under EN/IEC 62040-1 and 62040-2, the UPS meets global standards for electrical safety and electromagnetic compatibility.

Energy Efficiency

Features Green Mode for optimized energy savings without compromising protection.

Technical Specifications

  • Model: SRTG10KXLI
  • Capacity: 10kVA / 10kW
  • Topology: Double-Conversion Online
  • Input Voltage: 230V AC (160–285V range)
  • Output Voltage: 230V AC (Configurable 220/230/240V)
  • Output Connections: 2×IEC C13 + 1×IEC C19 + Hardwire
  • Battery Voltage: ±192V DC
  • Battery Type: Sealed Lead-Acid
  • Recharge Time: 4 Hours
  • Runtime: Scalable with external battery packs
  • Waveform: Pure Sine Wave
  • Transfer Time: Zero (true online)
  • Frequency: 50/60Hz ±3Hz
  • Efficiency: Up to 93.5%
  • Interface Ports: RJ-45, USB, SmartSlot
  • Dimensions: 217mm (H) × 440mm (W) × 620mm (D)
  • Weight: 81–101 kg (depending on configuration)
  • Operating Temp: 0–40°C
  • Humidity: 0–95% RH Non-Condensing
  • Noise Level: 55 dBA
  • Protection Class: IP20
